Product parameters:
Suitable for kinds of flat-panel/glass/spindle shaped loure and electric multi point control window;
Simple but delicacy design;
Optiinal size and the size can be tailor-made as requirement;
Smooth and strong output;
Electronic overload cutoff protector;
Endurance tests(30,000 cycles)are carried out;
Strokes can be tailor-made as requirement;
Standard col is grey and col can be tailor-made;
Specifications |
Units |
Technical Data |
LYM-DC24V |
LYM-A220V |
Thrust / Relay |
N |
1000N/1500N |
1000N/1500N |
Maximum operating current |
A |
1.0/1.2 |
0.4/0.5 |
Travel distance |
mm |
50~300 |
50~300 |
Promote the speed of |
mm/sec |
~6 |
~6 |
Operating voltage |
V |
DC24V±10% |
AC220V±10% |
Ambient temperature |
0C |
—20~+75 |
—20~+75 |
Protection class |
IP |
65 |
65 | |
