Product parameters:
Suitable for kinds of small size sliding window,louvre and windows within the inverted;
Optional plugs for connection with window and the plug can be tailor-made;
Plug storke distance can be tailotr-made;
Optinal frame and the frame can be made as requirement ;
Can set synchonous function;
Col can be tailor -made;
Specifications |
Units |
Technical Data |
LH Series |
Thrust / Relay |
N |
500N |
Maximum operating current |
A |
1.0 |
Travel distance |
mm |
50~1000 |
Promote the speed of |
mm/sec |
~12 |
Operating voltage |
V |
DC24V±10% |
Ambient temperature |
0C |
—20~+75 |
Protection class |
IP |
32 | |
